LML Duramax full delete kit with Mini Maxx V2 tuner (2015.5-2016)
The 2015.5, 2016 LML Duramax Delete Kit with Mini Maxx V2 Tuner combines preloaded engine programming with DPF, DEF, and EGR removal hardware for supported Chevrolet Silverado and GMC Sierra HD pickups. The complete package reduces exhaust restriction, eliminates regeneration cycles, disables supported emissions monitoring, and provides selectable power settings for daily driving, towing, or stronger performance.
What's included in delete kit
-
Mini Maxx V2 Delete Tuner - The preloaded handheld programmer connects through the factory OBD2 port and requires no VIN submission, stock file, infolog, or separately prepared custom tune. The tuner provides live engine monitoring, diagnostic functions, selectable power levels, and return-to-stock functionality.
-
Preloaded Delete Calibration - The manufacturer-supported calibration disables supported DPF, DEF, and EGR monitoring after the factory emissions components are removed. The calibration also clears supported emissions codes and removes emissions-related limp mode when reduced-power operation is caused by the deleted equipment.
-
DPF Delete Pipe or Complete Exhaust System - Buyers can select a delete pipe, 4 inch exhaust, or 5 inch exhaust configuration. Each option replaces the restrictive diesel particulate filter section and reduces exhaust backpressure.
-
EGR Valve and Cooler Removal Kit - The LML EGR delete kit includes block-off components, fittings, gaskets, and installation hardware required to remove the factory exhaust gas recirculation system and EGR cooler.
-
Installation Hardware - The package includes the clamps, fasteners, brackets, seals, and supporting hardware required for the selected exhaust and EGR configuration.
-
Installation Instructions - Detailed instructions explain the mechanical installation and the correct programming sequence for the handheld tuner.
Vehicle compatibility
-
Years: 2015.5, 2016
-
Makes: Chevrolet, GMC
-
Models: Silverado 2500HD / 3500HD, Sierra 2500HD / 3500HD
-
Engine: 6.6L LML Duramax Turbo Diesel
-
Body style: Pickup
-
Fuel type: Diesel
The LML Duramax delete kit is intended for 2500 and 3500 pickup applications.
Note: This package only fits late model 2015 and 2016 models with a three-bolt flange. For early 2015 models with a V-band flange, please refer to our alternative solution.
Performance & tuning
-
No forced regens
-
Improved throttle response
-
More controlled towing power
-
Potential fuel economy gains
-
Reduced exhaust restriction
-
Fewer emissions-system failures
Gains by power level
|
Power level |
+HP |
Best for |
|---|---|---|
|
Stock |
0 HP |
Factory-like driving and light work |
|
Tow |
+50 HP |
Heavy towing and loaded driving |
|
Street |
+100 HP |
Daily driving and stronger response |
|
Performance |
+150 HP |
Maximum supported performance |
Published torque gains are not provided as a fixed lb-ft value. Actual torque depends on the selected calibration, engine condition, transmission condition, tire size, fuel quality, elevation, and installed modifications.
Performance summary
|
Feature |
Typical result |
Important note |
|---|---|---|
|
Regeneration cycles |
Eliminated |
Requires correct hardware removal and programming |
|
Throttle response |
Improved |
Varies by selected power setting |
|
Fuel economy |
May improve under favorable conditions |
Results depend on speed, load, tires, and driving style |
|
Exhaust restriction |
Reduced |
Depends on pipe diameter and muffler choice |
|
EGTs |
May be lower under comparable load |
Towing weight and driving conditions affect exhaust temperature |
|
Towing response |
Stronger power delivery may be available |
Factory GVWR, GCWR, axle, and payload limits remain unchanged |
|
Reliability |
Removes common aftertreatment failure points |
Existing engine or transmission problems are not repaired |
|
Live monitoring |
Supported |
Available through the tuner display |
|
Return to stock |
Supported |
Factory hardware must also be reinstalled for a full stock configuration |
Which configuration should you choose?
The selected exhaust and muffler configuration determines installation layout, exhaust volume, and cabin sound.
|
Option |
Choices |
Recommended for |
|---|---|---|
|
Exhaust replacement |
DPF delete pipe |
Retaining the factory rear exhaust section |
|
Exhaust diameter |
4″ exhaust |
Daily driving, towing, and balanced sound |
|
Exhaust diameter |
5″ exhaust |
Deeper tone and larger exhaust appearance |
|
Muffler |
Straight pipe |
Maximum exhaust sound |
|
Muffler |
With muffler |
Reduced drone and quieter highway driving |
|
Power setting |
Stock or Tow |
Work use and regular towing |
|
Power setting |
Street or Performance |
Stronger acceleration and performance use |
How the delete kit works on your LML Duramax
The DPF delete process replaces the factory aftertreatment system with compatible hardware and ECM programming. After the supplied calibration is installed, the ECM no longer monitors the removed DPF, DEF, and EGR components, helping prevent regeneration requests, DEF warnings, EGR-related fault codes, and reduced-power operation caused by missing emissions equipment.
-
Remove the factory particulate filter and DEF components.
-
Install the selected pipe or complete exhaust system.
-
Remove the EGR valve and cooler hardware.
-
Connect the handheld programmer through the OBD2 port.
-
Flash the preloaded calibration and select power.
Installation information
The LML delete kit includes detailed instructions for the mechanical installation and programming sequence. A customer with solid mechanical experience can install the hardware independently, although seized exhaust fasteners and limited engine-bay access can increase the required time.
The tuner should be programmed before or immediately after the emissions hardware is removed according to the supplied instructions. Stable battery voltage must be maintained during the flash process to prevent programming interruption.
Technical specifications
|
Specification |
Detail |
|---|---|
|
Product type |
Full DPF/DEF/EGR removal bundle |
|
Vehicle make |
Chevrolet / GMC |
|
Engine |
6.6L LML Duramax |
|
Fitment years |
2015.5-2016 |
|
Models |
Silverado / Sierra 2500 and 3500 |
|
Tuner model |
Mini Maxx V2 |
|
Tune type |
Preloaded |
|
Flash method |
Factory OBD2 port |
|
Power settings |
Stock / Tow / Street / Performance |
|
Power listed gains |
0HP / +50HP / +100HP / +150 HP |
|
Exhaust options |
Delete pipe, 4″ system, or 5″ system |
|
Muffler options |
Straight pipe or with muffler |
|
Exhaust material |
Stainless steel |
|
Components removed |
DPF · DEF/SCR · EGR |
|
Live engine data |
Supported |
|
Diagnostic functions |
Supported |
|
Return to stock |
Supported through tuner menu |
No More Emissions Codes
Correct installation and programming disable supported dashboard warnings and diagnostic trouble codes associated with the removed DPF, DEF, SCR, and EGR systems.
DPF System
|
Code |
Description |
|---|---|
|
P2002 |
Diesel Particulate Filter Efficiency Below Threshold |
|
P242F |
Diesel Particulate Filter Ash Accumulation |
|
P2452 |
Diesel Particulate Filter Pressure Sensor "A" Circuit |
|
P2453 |
Diesel Particulate Filter Pressure Sensor "A" Circuit Range / Performance |
|
P2458 |
Diesel Particulate Filter Regeneration Duration |
|
P2459 |
Diesel Particulate Filter Regeneration Frequency |
|
P2463 |
Diesel Particulate Filter Restriction - Soot Accumulation |
|
P246C |
Diesel Particulate Filter Restriction - Forced Limited Power |
DEF / SCR System
|
Code |
Description |
|---|---|
|
P203B |
Reductant Level Sensor Circuit Range / Performance |
|
P204F |
Reductant System Performance |
|
P205B |
Reductant Tank Temperature Sensor Circuit Range / Performance |
|
P207F |
Reductant Quality Performance |
|
P208A |
Reductant Pump Control Circuit |
|
P20B9 |
Reductant Heater "A" Control Circuit Open |
|
P20BA |
Reductant Heater Performance |
|
P20EE |
SCR NOx Catalyst Efficiency Below Threshold |
|
P229F |
NOx Sensor Circuit Range / Performance |
|
P249D |
Closed-Loop Reductant Injection Control at Limit - Flow Too High |
EGR System
|
Code |
Description |
|---|---|
|
P0401 |
Exhaust Gas Recirculation Flow Insufficient |
|
P0402 |
Exhaust Gas Recirculation Flow Excessive |
|
P0403 |
Exhaust Gas Recirculation Control Circuit |
|
P0404 |
Exhaust Gas Recirculation Range / Performance |
|
P0405 |
Exhaust Gas Recirculation Sensor "A" Circuit Low |
|
P0406 |
Exhaust Gas Recirculation Sensor "A" Circuit High |
|
P046C |
Exhaust Gas Recirculation Sensor "A" Circuit Range / Performance |
|
P2457 |
Exhaust Gas Recirculation Cooler Efficiency Below Threshold |
Send the truck's VIN, model year, body style, and modification list to our diesel specialists for confirmation of the correct package before ordering.
